Quality Test

Optima Gearboxes undergo stringent test bench and production tests to guarantee reliability, high performance, and efficiency in the field #optimadrivetechnology #powertakeoff #PTO #sewercleaning #combi #jetting #vacuum #concrete #sweeper #spritz #ssu #driveline #transmission  #splitterbox #clutch #powerclutch #fire #firefighting #firefighter #drilling #drillingrig #performance #gearboxsolution #oilfieldequipment #gearbox #oem #engineering #gears #gearboxes

Smart PTO

Optima Launched Smart PTO Clutches for Direct-Driven Vehicles like Crushers.

Hydraulic Pump Drives - 3 PAD

Optima Model OPS-543 is a 3 PAD Hydraulic pump drive designed for direct mounting to industrial engines via an SAE flange and driven in standard engine rotation.  #twindisc #stiebel #brevini #pumpdrive #gearbox

Transfer Case

The Transfer Case OPS923 (with CLUTCH and DIRECT DRIVE version) has been designed primarily for use in dry vacuum equipment and combination sewer cleaning machines. Equivalent to PCV 3000 and Fabco PTO-175,  #gearbox #transfercase  #splitterbox #clutch #powerclutch #ssu #sewercleaning #combi #jetting #vacuum #concrete #sweeper #driveline #transmission #fire #firefighting #firefighter #drilling #drillingrig #performance #gearboxsolution #oilfieldequipment

transfer cases direct mount of axial piston pumps

Optima transfer cases with two or four outputs for direct mount of axial piston and gear type hydraulic pumps.  Applications: Concrete Pumping Equipment, Sewer Cleaning Combination Machines, Fire Trucks, and Drilling Rigs.

Engine Mount Transfer Case

Engine-driven power take-offs for truck-mounted equipment and industrial applications.  Applications: Cement Mixers, Concrete Pumpers, Sewer Cleaning Combination Machines, Street Washer, Fire Trucks, and Drilling Rigs. The PTO can be installed in most brands of vehicles provided to the market without engine-driven power take-off. Available with three speed-increase ratios and one or two clutch-controlled outputs. Aluminum alloy housing. Stone crushers and Wood Chippers. The PTO can be installed on a diesel engine with an SAE flange in which it is required a through output coupled with a clutch or a hydrodynamic PTO and auxiliary outputs for various services. engine mount gearbox, engine mount transfer case, engine mount pump drive,

OPS923/H For Hydrostatic and Mechanical Transmission

OPS-923/H Hydrostatic Gearbox with speed reducer. Available drive ratios (with Speed Decrease) Hydraulic motor ratio is: i = 1:17,28 APPLICATION: The Transfer Case OPS-923/H has been designed primarily for dry vacuum equipment, road, and airport maintenance vehicles for asphalt regeneration, and vehicles for hi-rail applications.  The OPS-923/H is a unit pertaining to the family of Transfer Cases OPS-923 (Direct Drive, Disconnect, W/C) with a hydrostatic case module mounted at the main transmission output. This group allows the hydrostatic drive of the vehicle by installing a hydraulic pump and hydraulic motor at the transfer case and hydrostatic case module respectively. The transferring of the vehicle is achieved with the capability of varying the forward speed without affecting the operational speed of the equipment. The hydrostatic case module, designed for a number of applications, provides several reduction drive ratios. This allows drive systems where very slow speeds are required as 0.05 Km - 1.5 km/h (0.03 MPH - 1 mph) or higher speeds up to 25 - 30 km/h (16 MPH – 19 MPH).

Engineering Your Success

#optimadrivetechnology #gearboxsolution #splitshaftpto #transfercase #gearbox #powertransmission #gearboxes #gears #engineering #OEMs #quality #getriebe #Verteilergetriebe #Nebenantrieb

Another successful project in far east Asia.

OPS-481 Transfer Case with 30L gear pumps. #gearboxsolution #transfercase #splitshaftpto #powertakeoff #gears #gearboxes #sewercleaning #combi #jetting #vacuum #concrete #sweeper #spritz #ssu #driveline #transmission #splitterbox #pto #cleaningvehicle #sewercleaning #garbagetruck #sweepers#platformtruck #SewersuctionJettingMachine  #powertransmission #HydraulicsForTrucks

GEARBOXES FOR GENERAL MECHANICAL ENGINEERING

UP TO ANY CHALLENGE Wherever an individual drive solution is needed in the area of mechanical engineering and in general automotive engineering, we are the right contact thanks to our competence and experience and are open to any challenge. Particularly in the area of electromobility, we contribute our expertise and experience when it comes to the electrification of drive trains. In electric vehicles, our special gearbox solutions help to increase energy efficiency and reduce the costs of the entire drive system.  SPEED-CHANGE GEARBOX, SPECIAL GEARBOXES, SPUR GEARBOX,

.

Transfer Cases for Firefight Vehicles

There is always a strong partner behind your truck

creep drive

Customers of Optima’s have been using creep drives designs. These units shown in the picture are getting close to shipment and will be used in a guardrail truck application.  The creep drive allows the vehicle to creep along at very low consistent speeds, regardless of the engine speed.  This in turn allows the auxiliary systems to utilize the power needed to perform the work needed effectively.  The vehicle is then able to drive at a normal speed once the system is disengaged.

SPEED REDUCER

Custom Speed Reducer Gearboxes – Numerous Sizes OPS562 | SPEED REDUCER, SPEED-CHANGE GEARBOX,  Torque max 400 HP Ratio1-1/4 Rotational speed max 2500 rpm  Weight178 KG * speed reducer (PTO, reduce the engine speed). * OPS562 speed reducer is suitable for 26-ton vehicles. * Designed to reduce the vehicle speed. Like: road marking, street marking vehicles. * The direction of rotation is the same as the engine. #madebyOPTIMA #roadmarking #streetmarkingvehicles #speedreducer #getriebe #verteilergetriebe #dropbox #optimadrivetechnology #OEMs #quality #engineering #powertransmission #gearbox #gearboxes #gears

NEW HYDROSTATIC TRANSFER CASE

For Hydrostatic and Mechanical Transmission. The Hydrostatic Transfer Case OPS-923/H has been designed primarily for dry vacuum equipment, road, and airport maintenance vehicles for asphalt regeneration, and vehicles for hi-rail applications. The OPS-923/H is a unit pertaining to the family of Transfer Cases OPS-923 (Direct Drive, Disconnect, W/C) with a hydrostatic case module mounted at the main transmission output.  This group allows the hydrostatic drive of the vehicle by installing a hydraulic pump and hydraulic motor at the transfer case and hydrostatic case module respectively. The transferring of the vehicle is achieved with the capability of varying the forward speed without affecting the operational speed of the equipment. The hydrostatic case module, designed for a number of applications, provides several reduction drive ratios. This allows drive systems where very slow speeds are required as 0.05 Km - 1.5 km/h (0.03 MPH - 1 mph) or higher speeds up to 25 - 30 km/h (16 MPH – 19 MPH). The operation of the hydrostatic case module is achieved with a control independent from the main drive disconnect control. Based on this, it is imperative to install an interface safety system that prevents the engagement of the hydrostatic case module without first disengaging the main drive to the differential.  Equivalent to omsi PFT-PCH/3000, PCH-3000,  Hydrostatic gearbox, Hydrostatic Split Shaft PTO,

Reduction Gearboxes and Power Take Off's

OP75 8x8, GVW 30 tonnes

Our vertical arrangement having a modular concept with many options like split torque differential, parking brake, PTO, emergency steering pump, direct mount provision for Allison transmissions, and others. The significant advantage of the OPTIMA transfer case is compact dimensions, high efficiency, and low noise level as a product of company engineering knowledge and best gearing technology. Suitable for 4x4, 8x8 vehicles

DIRECT MOUNT TRANSFER CASE

Optima offers Direct Mount Transfer Cases.  Direct mount to Engine or Transmission -especially for ALLISON transmissions. #allison 4000, 3000, 1000 - 2500 series, MD 3500, 1000, 2500,

Horizontal Split Shaft PTO

A shot before shipment.  OPS-331 alternative to PFT-PC4/3000, PFT-PC2/3000. Main Drive Max. continuous torque Max. intermittent torque Max.Speed 2.141 Kgm | 21.000 Nm 3.000 Kgm | 29.419 Nm 2,500 – 3,300 RPM

OPS-222 For Hydrostatic and Mechanical Transmission

The Transfer Case OPS-222 has been designed primarily for dry vacuum equipment, road, and airport maintenance vehicles for asphalt regeneration, and vehicles for hi-rail applications. Equivalent to PFT–PCH/3000.  creep drive transfer case, creep drive,

Transfer Case for Concrete boom trucks

OPTIMA designs and manufactures gear units and power transmission components for the Construction industry. Here is the OPS-412 twin output transfer case, working on the concrete boom truck.  Equivalent to Stiebel 4324.22, 4194.51, 4195, Schwing 4194 (10096196, 10173816), 4195, PTO /Sermac-2461215  #schwingstetter #schwing #S47SX #concretepump #autobetonpumpe #constructionmachinery #constructionequipments

Mechanical & Hotshift PTOs

Volvo I Shift PTOs, Mack M drive PTOs, Hotshift PTOs, Mechanical PTOs. 1198K03, 1196K03, 11111K03, 11112K03, 11113K03, 11109K52, 11107K***, 11106K03, 7022904, 3300, Allison / Aisin, 3200 / 3800, Eaton Fuller, 3900/3920 Series Ford, 3000, 3131, 3131RP, 3190, 3151, 3252, 1000/2000, 4100 Series, 4200/4250 Series, 6000/6800/8000, 8500,

Optima PTOs Cross Reference

Optima, Bezares, Eaton, Muncie, Chelsea PT1000XBN011RA TG6S-U6806-P1KX 442XFAHX-V3XK PT1000XJN011SE TG6S-U6810-P1BX 442XRAHX-V3XD PT1000XCW011RA TG6S-U6807-C1KX 442XLAHX-W3XK PT2000XBN011SE TG8S-U6806-P1BX 489XFAHX-V3XD PT2000XBN011RA TG8S-U6806-P1KX 489XFAHX-V3XK PT2000XCN011RA TG8S-U6807-P1KX 489XLAHX-V3XK PT2000XCN011SE TG8S-U6807-P1BX 489XLAHX-V3XD PT2000XCN013RA TG8S-U6808-P3KX 489XLAHX-V5XK PT2000XEN011RA TG8S-U6809-P1KX 489XQAHX-V3XK PT2000XEN011SE TG8S-U6809-P1BX 489XQAHX-V3XD PT2000XEN013RA TG8S-U6809-P3KX 489XQAHX-V5XK PT2000XJN011RA TG8S-U6810-P1KX 489XRAHX-V3XK PT2000XJN011SE TG8S-U6810-P1BX 489XRAHX-V3XD PT2000XON011SE TG8S-U6812-P1BH 489XSAHX-V3XD PT2010XCN243RA TG8D-M6508-P3KX 489ZLDAX-V5XK PT2010XAN751RA TG8F-E8006-P1KX 489QCLZX-Q3SK PT2010XBN751RA TG8F-E8007-P1KX 489QFLZX-Q3XK PT2010XCN751RA TG8F-E8008-P1KX 489QHLZX-Q3XK PT3252PBE633SA CS24-A1005-H3KX 277XBFJP-B5RA PT3252PBE633SA CS20-A1005-H1KX 278XBFJP-B5RA PT3900PEE654SE FR64-F1506-D4NX 247FMKSP-B216 PT3920PEE713SF FR66-F1209B3NX 249FMLLX-B416 PT4100XCN011RJ SH8S-U6807-P1EX OUTPUT N/A PT4100XCN013RJ SH8S-U6807-P3EX OUTPUT N/A PT4100XEN011RB SH8S-U6809-P1PX 680XQAHX-V3AF PT4100XEN011SE SH8S-U6809-PIBX 680XQAHX-V3XD PT4100XEN011IC SH8S-U6809-P1CX 680XQAHX-V3XV PT4100XJN011IC SH8S-U6810-P1CX 680XRAHX-V3XV PT6000XCN011SE RL6S-U6805-P1BX 340XFAHX-V3XD PT6800XBN011SE RL8S-U6805-A3BX 348XFAHX-V3XD PT8000XBN013IC 838S-U6806-L3CX 863XBAHX-Y5XV PT8000XBN243IC 838S-M6506-L3CX 863XBDAX-Y5XV PT8500XJN011RJ 828S-U6810-P1EX 880XMAHX-V3XS PT8500XRN011IC 828S-U6812-P1CX 880XQAHX-V3XV PT4100XCN011RJ 828S-U6810-P1EX 880XMAHX-V3XS PT4100XEN011IC 828S-U6812-P1CX 880XQAHX-V3XV PT4100XJN011IC 828S-U6813-P1CX 880XRAHX-V3XV PT4110XBN751RJ 828F-E8009-TIEX 880QJLZX-Q3XS PT4110XEN751IC 828F-E8013-T1CX 880QQLZX-Q3XV PT1198K03 + PT116504 RS4S-P86VM-P1CX 523XTASX-H-XY

PTO for Allison 3000 Gearboxes

Optima OPS-672 PTO for Allison 3000 Gearboxes.  Parker Chelsea 489 Series Power Take-Off (PTO), Chelsea 280 Series is a hydraulically shifted hot shift PTO, Chelsea 210 Series PTO, Chelsea 249 Series PTO, Chelsea 870-XL Series Powershift PTO, Chelsea 267 Series is a 10-Bolt PTO designed to fit Allison and CAT automatic transmissions, Chelsea 880 Series, Chelsea 645 Series, Chelsea 870 Series powershift PTO, Chelsea 912 Series Split Shaft PTO/gear box, Chelsea 890 Series, Chelsea 524 Series Rear Mount PTO, Chelsea 272 Series Hot Shift 6-Bolt PTO, Chelsea 442 Series, Chelsea 680 Series PTO, Chelsea 249V Series, Chelsea 272-F Series, Chelsea 823 Series, Chelsea 897 Series, Chelsea 877 Series, Chelsea 282, Chelsea 340, Chelsea 221, Chelsea 626, Chelsea 628, Chelsea 630, Chelsea 660, Chelsea 852, Chelsea 541, Chelsea 885, Chelsea 252, 287 is a Heavy Duty Constant Mesh PTO, Chelsea 447 Series, Chelsea 901 Series Split Shaft gearbox, Chelsea 899 Series,  Chelsea 290 PTO, Mechanical Shift Rear Mount Power Take-Off (PTO) - 511 Series, 590 Series PowerShift (Hydraulic) Rear Mount PTO, Chelsea 348, Chelsea 2442 Series PTO, Chelsea 892 Series was designed to fit the Allison 4700 Series transmissions. Chelsea 863 Series Power Take-Off (PTO) is a Forward and Reverse PTO, Chelsea 352 Series PTO, Chelsea 247, Chelsea 877-XL Series PowerShift PTO, Chelsea 100 Series PTO, Chelsea 2230U Series Front Mount Gear Box, Chelsea 230, Chelsea 231 Series, Chelsea 236 Series, Chelsea 238 Series, Chelsea 243 Series, Chelsea 269 Series, Chelsea 270,  Chelsea 271 Series, Chelsea 277, Chelsea 278, Chelsea 429, Chelsea 435 Series Power Take-Off (PTO), Chelsea 452 Series Dual Shaft Power Take-Off (PTO), Chelsea 522 Series Rear Mount PTO was designed for the ZF, Chelsea 523 Series, Chelsea 800 Series, Chelsea 812, Chelsea 859, Chelsea 867, Chelsea 941 Series Split Shaft PTO/gearbox, Chelsea & Muncie PTO's & parts

Optima-Bezares-Chelsea-Muncie

CROSS Reference   Bezares  Chelsea Muncie Optima Gearboxes Notes 1000 1010 442X 442G 442Z TG6S TG6B TG6D     SAE Six Hole, Two Gear-Single Speed Lateral 6 tal. 2 Engranajes 2000 489X 489G TG8S TG8B     SAE Eight Hole, Two Gear-Single Speed Lateral 8 tal. 2 Engranajes 2010 489Z TG8D       3000 271M     AT 500 Series, Allison MT 600 Series, HT 700 Series Side Mount Pneumatic / Hydraulic Lateral Neumático / Hidráulico 3100   CS24 CS25       3131 870X CS11   MD-3000/3060/3066/3070/3200/3500/3560 HD-4000/4060/4500/4560/4700/4800   3151 877X CD10     Constant Mesh, Heavy Duty Toma Constante, Reforzado 3131RP 890X 890L 890R 3131RP 890H 890E 890T 890U     MD-3000/3060/3066/3070/3200/3500/3560 HD-4000/4060/4500/4560/4700/4800 Rear Pump Bomba Posterior 3200 272X       Side Mount, Pneumatic Lateral, Neumático 3252 280G HS24 OPS-862 MD-3000/3060/3066/3070/3200/3500/3560 HD-4000/4060/4500/4560/4700/4800   3300 272A 272D 272G CS6S CS6B       3800 282X CS8S CS8B     Bottom, Pneumatic Inferior, Neumático 3810 282Z CS8D       3900 247F FR67 FR63 FR64   Ford 5R 110W   3920 249F FR66 FR6Q   Ford 6R140 (MY 2011 SUPER DUTY) Side Mount, Hydraulic Lateral, Hidráulico 4100 680X 680G SH8S SH8B       4110 680Z SH8D     Pneumatic Neumático 6000 340X 340G RL6D     SAE 6 Holes, forward & reverse output Type round shaft 1 1⁄4” 6005 340Z         6800 348X 348G RL8S RL8B       8000 863X 863G 838S 838B       8500 880X 880Z 880G 828S 828B     SAE 8 Holes, Heavy duty SAE 8 Taladros, Reforzado 6013399 941 SS66        95X13EIB       EATON EEO-14F112C /15F112C 16F112C /17F112C /18F112C Rear Mount Pneumatic Posterior Neumático 120X13DSB       Detroit DT-12 Rear Mount Pneumatic Posterior Neumático 4250         SAE 8 Hole, 2 independent outputs PTO SAE 8 Taladros, 2 salidas independientes Bezares PTO series: 1000, 2000, 3000, 3131, 3131RP, 3190, 3151, 3200, 3252, 3300, 3800, 3900, 3920, 4100 & 4110, 4250, 6000, 6800, 8000, 8500, 95X13EIB, 120X13DSB, AD_ _ _, AD-622, AD-68248, Bezares Allison 241703, 241903, 240503, 241003, 9058899, 034503, Eaton Fuller 126003,  1000 & 2000, 122703, 1216803, 1217103, 1216950, Eaton 1217203E, 1213203, 121903, 129803, 127503, 1213103, 129603, 125103, 1213403, 1219203, 1217903, 129703, 1210603, 123503, 1215303, 1213003, 1214603, 1219203, 1219003, 129503, 1210903, 1215550, 126503, 1212103, 1217802, 128504, 124303, 124203, 124603, 1212003, 125003, 1212403C, 1216002, 1213303, 1214503, 128604, GAZ  310203,  310303, Hino 263903, 263403, 263803,  261103,  260703,  260903,  261603,  261803,  262303,  264553, 262502,  264603,  264753,  264302, Hyundai  271303, 27__03,  271803, 270803,  270503, 271203,  270103, 270803, Isuzu 196303,  1911103,  190603,  195903,  196003,  192403,  196903, 196703,  197003,  1910503,  199303,  197703,  1910603,  197603, 197803,  198303,  198103,  198003, Iveco  067603,  065803,  068803,  065103,  068203,  06920_,  06107__,  062203,  061503,  068503,  062303,  062003,  063103,  063803,  067903,  065903,  064503,  066203,  067550,  067403,  064704,  067304,  061604, Kamaz  130830,  130903, Mack  210303,  210503, Maz 280103, 280303, 280203, Mercedes  07__03,  0718803, 0714003, 073503,  0724703,  070803,  0718403, 0710703, 074103,  0725002,  0719550, 0716303,  0725603, 0712103, 076003,  0725303,  0718103, 0710403, 078203,  0725903,  0719653, 07235K03, 07224K50, 07217K03, 07218K03, 07219K03, 07220K03, 07242K03, 07233K03, 07221K03,  0723452, 700904, Mitsubishi 171803,  176603,  177203,  175803,  175903,  176203,  177103,  177903,  179703,  1711830,  1712003,  177003,  176803,  176903,  177703,  174203,  1710303,  173103, 177403, Nissan  035603,  039502,  039203,  035103,  036803,  039303,  039403,  037903,  038803,  038503, Renault  026003,  024603,  024403, 020303,  027703, Scania 090203,  090403,  090703,  091203,  090603,  092650,  092750,  092850, 093_03,  093303, 093403, 093903,  1029_03,  093003, Shaanxi  301203, 301403,  301303, Spicer  180503, Tata  290803,  290903, Toyota  163603,  163703, 163803, 163903, 164303, Volvo  110203, 110403, 110603,1196K03, 11103K03, 1197K03, 1198K03, 11108K03, 1199K03, 1111_K03, 11101K03, 11106K03, 11107K_ _ _, 110404, 116604, 110204, 116704, VOLVO AT-2412C / 2412D / 2512C / 2612D / 2612E / 2812C / 2812D,R1000 / 1400 / 1700, SR1400 / 1700 / 1900 / 2000, SRO2400, VT1708 / 2009B / 2014B / 2214 / 2412B / 2512C / 2514B / 2812C, AT/DT,  ZF  1016903, 1017103,  1022503,  1018503,  109203,  1025803,  1018703,  1012003,  104703, 104603,  1020403,  1020103,  1020303, 1020203,  1021403J,  1024703,  1022603,  1027103, 1016103, 1016703, 1013703, 109903, 1026603,  1030903,  103__03, 1023603, 1024650, 1015K03, 1022003, 102K_03, 1015803, 1010K03, 1021503, 1026003, 1023003, 1019103, 1021803, 1028350, 1024203, 1022203, 1028103, 1027403,  1026950, 1012704, 1013004, 103304, 103404, 1011204, 103504, 103604, 1011304, 1026704, 1025404, 1018104,  1020804,  1021604,  1028804, 1029950, PTO MAN ENGINE D20 / D26,  D2868LF02, Engine Adapter Scania ED 120, Scania DS 14, ED 140,  ED 160, DC 16, Volvo D11, D13, D16, PTO 081703/1, 081903, 082403, 700704, 7012104,  709607, 706404, 7020404, 7014404,  7022204, 701504,  7021104, 7022904,  7028804,   GR 801, GR 900, GRH 900, GRS 890, GRS 900, GRS 920, GRSO 900, GR 875, GR 905, GRS 895, GRS 905, GRSO 905, GRSO 925, Eaton fuller 4106, 5206 DT/OD / FS-6406 AE,

Hot Shift, 2 gear Power Take-off

OPS862 - Hot Shift, 2 gear Power Take-off for Allison 3000 MD series transmission.  MD-3000/3060/3066/3070/3200/3500/3560  HD-4000/4060/4500/4560/4700/4800 Hot shift, 2 gear power take-off, with la ow profile. Hydraulic shifting and internal lubrication. Mounting on both sides of the transmission. Wide range of internal ratios and most output options: SAE B, SAE BB, or ISO 4 bolts. 24volt electric/hydraulic shift. Equivalent to Bezares 3252 (241703, 241903), Chelsea 280G and Muncie HS24 Series. Bezares PTO series: 1000, 2000, 3000, 3131, 3131RP, 3190, 3151, 3200, 3252, 3300, 3800, 3900, 3920, 4100 & 4110, 4250, 6000, 6800, 8000, 8500, 95X13EIB, 120X13DSB, AD_ _ _, AD-622, AD-68248, Bezares Allison 241703, 241903, 240503, 241003, 9058899, 034503, Eaton Fuller 126003,  1000 & 2000, 122703, 1216803, 1217103, 1216950, Eaton 1217203E, 1213203, 121903, 129803, 127503, 1213103, 129603, 125103, 1213403, 1219203, 1217903, 129703, 1210603, 123503, 1215303, 1213003, 1214603, 1219203, 1219003, 129503, 1210903, 1215550, 126503, 1212103, 1217802, 128504, 124303, 124203, 124603, 1212003, 125003, 1212403C, 1216002, 1213303, 1214503, 128604, GAZ  310203,  310303, Hino 263903, 263403, 263803,  261103,  260703,  260903,  261603,  261803,  262303,  264553, 262502,  264603,  264753,  264302, Hyundai  271303, 27__03,  271803, 270803,  270503, 271203,  270103, 270803, Isuzu 196303,  1911103,  190603,  195903,  196003,  192403,  196903, 196703,  197003,  1910503,  199303,  197703,  1910603,  197603, 197803,  198303,  198103,  198003, Iveco  067603,  065803,  068803,  065103,  068203,  06920_,  06107__,  062203,  061503,  068503,  062303,  062003,  063103,  063803,  067903,  065903,  064503,  066203,  067550,  067403,  064704,  067304,  061604, Kamaz  130830,  130903, Mack  210303,  210503, Maz 280103, 280303, 280203, Mercedes  07__03,  0718803, 0714003, 073503,  0724703,  070803,  0718403, 0710703, 074103,  0725002,  0719550, 0716303,  0725603, 0712103, 076003,  0725303,  0718103, 0710403, 078203,  0725903,  0719653, 07235K03, 07224K50, 07217K03, 07218K03, 07219K03, 07220K03, 07242K03, 07233K03, 07221K03,  0723452, 700904, Mitsubishi 171803,  176603,  177203,  175803,  175903,  176203,  177103,  177903,  179703,  1711830,  1712003,  177003,  176803,  176903,  177703,  174203,  1710303,  173103, 177403, Nissan  035603,  039502,  039203,  035103,  036803,  039303,  039403,  037903,  038803,  038503, Renault  026003,  024603,  024403, 020303,  027703, Scania 090203,  090403,  090703,  091203,  090603,  092650,  092750,  092850, 093_03,  093303, 093403, 093903,  1029_03,  093003, Shaanxi  301203, 301403,  301303, Spicer  180503, Tata  290803,  290903, Toyota  163603,  163703, 163803, 163903, 164303, Volvo  110203, 110403, 110603,1196K03, 11103K03, 1197K03, 1198K03, 11108K03, 1199K03, 1111_K03, 11101K03, 11106K03, 11107K_ _ _, 110404, 116604, 110204, 116704, VOLVO AT-2412C / 2412D / 2512C / 2612D / 2612E / 2812C / 2812D,R1000 / 1400 / 1700, SR1400 / 1700 / 1900 / 2000, SRO2400, VT1708 / 2009B / 2014B / 2214 / 2412B / 2512C / 2514B / 2812C, AT/DT,  ZF  1016903, 1017103,  1022503,  1018503,  109203,  1025803,  1018703,  1012003,  104703, 104603,  1020403,  1020103,  1020303, 1020203,  1021403J,  1024703,  1022603,  1027103, 1016103, 1016703, 1013703, 109903, 1026603,  1030903,  103__03, 1023603, 1024650, 1015K03, 1022003, 102K_03, 1015803, 1010K03, 1021503, 1026003, 1023003, 1019103, 1021803, 1028350, 1024203, 1022203, 1028103, 1027403,  1026950, 1012704, 1013004, 103304, 103404, 1011204, 103504, 103604, 1011304, 1026704, 1025404, 1018104,  1020804,  1021604,  1028804, 1029950, PTO MAN ENGINE D20 / D26,  D2868LF02, Engine Adapter Scania ED 120, Scania DS 14, ED 140,  ED 160, DC 16, Volvo D11, D13, D16, PTO 081703/1, 081903, 082403, 700704, 7012104,  709607, 706404, 7020404, 7014404,  7022204, 701504,  7021104, 7022904,  7028804,   GR 801, GR 900, GRH 900, GRS 890, GRS 900, GRS 920, GRSO 900, GR 875, GR 905, GRS 895, GRS 905, GRSO 905, GRSO 925, Eaton fuller 4106, 5206 DT/OD / FS-6406 AE,  Used Trucks ISUZU / KENWORTH / PETERBILT / FORD / MITSUBISHI / DETROIT DIESEL / ZETROS MERCEDES / 180E28 IVECO / 65CF-240 DAF / DENNIS Elite / DENNIS Elite Kerbsider / DENNIS Sabre XL / PRO 628 BMC / MITSUBIHI FUSO FIGHTER / SEDDON / ML160E24 IVECO / ATEGO / SCANIA P340 / HINO 268A / 2628LL Econic MERCEDES BENZ / UD 2600 / HINO USA NV8J / TERBERG VOLVO  #hotshift #withclutch #allison #bezares #muncie #ParkerChelsea #chelsea #PTO #forNortAmerica #truck #power #trucks #Hydraulics #HydraulicSystems #Parker #transmission #parts #WetKit #fluidpower #garbagetrucks  #maintenance #equipment #hydraulic #dumptruck #truck

VERTICAL TYPE SPLIT SHAFT PTO

OPS371 has been specifically designed for sewer cleaning trucks. OPS371 is a split shaft power take-off whose dimensions and performance are particularly suitable for driving through cardan shafts hydraulic pumps, blowers, compressors above the lorry’s frame. The flange for Cardan shafts can be mounted both on differential and/or cabin sides. On the opposite side, there is the possibility of having a flange for the direct mounting of a hydraulic pump.  Equivalent to:  omsi PFT 3000/4AV-E (PFT-4AV-E/3000), PFT-3000/2AV,  Muncie SSV series.  PZB 42903, 42904, 42905, 42906, 32903, 32904, 32905, 32906.

HYDRO-MECHANICAL DRIVES

OPTIMA designs and produces hydro-mechanical transmission units for special lorry applications. Their position between the gearbox and rear axle makes it possible to change vehicle drive from mechanical to hydrostatic via a dedicated hydraulic circuit. Designed for controlled speed, OPTIMA hydro-mechanical transmission systems have an additional PTO that eliminates the need for an auxiliary engine. Possible applications include road sweepers, road washers, ground support equipment, firefighting equipment, snowplows, and cranes.

SPEED REDUCER

OPTIMA SPEED REDUCER - OPS462 Power: 200 HP Ratio: 1-1/4 * Speed Reducer (PTO, reduce the engine speed.) * The direction of rotation is the same as the engine.  * for Medium size trucks #madebyoptima #optimadrivecpomponents #optimagearboxes #speedreducer #reductiongearbox #acceleration #deceleration

ENGINE MOUNT TRANSFER CASE

SAE 4 engine mounting transfer case. Working with Pneumatic Clutch System

Optima Transfer Case

Optima Transfer Cases are specially developed for mobile machines, large suction vehicles, high-pressure cleaning, and combination vehicles.  #splitshaft #splitshaftpto #sewercleaning #vacuumtrucks #SewersuctionJettingMachine

2 SPEED TRANSFER CASES

OPTIMA offers a wide range of transfer cases for heavy-duty industrial vehicles and with all kinds of specially customized solutions. We are proud to be a part of this unique project in the north of the world. Powered by Optima OPS0573 - 2 SPEED TRANSFER CASES and Caterpillar C32 engine. This is the biggest bus in the world.  https://www.youtube.com/watch?app=desktop&v=nfjV1DpSAZ0

SPLITTER GEARBOX FOR ISO 4 BOLT PUMPS

Direct pump mounting version available. Equivalent to interpump/PZB 3.4.2.6 SPLITTER GEARBOX FOR ISO 4 BOLT PUMPS The splitter gearbox is a gearbox that allows multiple outputs from a single input, which can be used for: - forestry and grab cranes with two separate hydraulic circuits, - flour, grain, cement, etc. The tank where a hydraulic pump and compressor are needed to tip and blow, - or any other application where various separate drives are required. Depending on which unit is selected it is possible to increase or reduce output speed if required. However, a 1:1 ratio version is available.

Custom-made gearboxes

We develop individual solutions together with our partners and are dedicated to all challenges. Custom-made gearboxes for the agriculture industry.   equivalent to Katsa Distribution gearboxes L150, L350, L490, L700 Series, PTO345 Series, PTO350 Series, PTO500 Series, PTO525 Series.

Engine PTO, Sandwich PTO, Flywheel PTO, Gearbox pto,

High torque power take-off (flywheel power take-off). PTO-OPS492 is sandwich-mounted high torque power take-off options available for ISUZU Trucks. The high torque power take-off is fitted between the engine and the gearbox. The drive is taken from the engine crankshaft. The high torque power take-off is suitable for applications in which the power take-off must be clutch independent. It can operate when the vehicle is moving as well as when it is stationary. The high torque power take-off is suitable for applications such as: • Concrete pumps • Sludge/suction vehicles • Sweepers • Fire trucks/Skylifts * Engine PTO, Sandwich PTO, Flywheel PTO, Engine Flywheel PTO, Gearbox PTO,

Direct hydraulic pump mounted PTO

*OPS-331/H direct hydraulic pump mounted product. Designed for hydraulic driven vehicles. Split shaft drives

Stiebel type Transfer Cases

OPTIMA offers a wide range of transfer cases for Truck-mounted concrete pumps, like Schwing Stetter, Putzmeister, Sermac, Cifa, Liebherr and many others.  OPS-952 (Stiebel 4496, G64, 4599). Gear box G-64 OPS-412 (Stiebel 4324.22, Schwing 4194, 4195, PTO/Sermac-2461215) Caja de transferencia, Caja transfer para Schwing, Sermac.  caja de transferencia, caja de transfer, caja de cambios, caja transfer, caja reductora, ​Cajas De Velocidades, Bombas pluma para concreto

Auxiliary Drives - PTO's

OPTIMA offers a wide range of Auxiliary Drives - PTO's for Mercedes, Volvo, Scania, ZF, Eaton, Fuller, Allison, Parker Chelsea transmissions.  CLUTCHED POWER TAKE-OFFS, Clutch-dependent power take-off,

PUMP DRIVES

OPTIMA offers a wide range of Pump drives for heavy-duty industrial vehicles and with all kinds of specially customized solutions. Equivalent to Stiebel, Twin Disc, Liebherr, and so on.  Twin Disc Pump Drive AM220, AM230, AM232, AM320, AM345, AM365, AM450, AM100, AM110, AM216, AM220, AM230, AM232, AM270, AM320, AM330, AM345, AM365, AM370, AM450, AM480.  Stiebel 4381 (P2000), 4380, 4504, 4363 / 4360, 4370 ( P2000 ), 4390, 4362 ( P2000 ), 4382, 4392, 4384, Stiebel 4394 (P2000), 4325 / 4525, Stiebel 4504, 4363, 4370, 4371, 4380, 4390, 4331, 4362, 4372, 4373, 4382, 4392, 4332, 4384, 4399, 4561, 4394, 4325, 4395, 4572. Liebherr Type Splitter box - pump drives - Pumpenverteilergetriebe. PVG250B, PVG300B, PVG 350 B, PVG 200 C, PVG 250 C, PVG 300 C, PVG 400 C, PVG 450 C, PVG 450 D, PVG 500 M, PVG 600 E

HYDRO-MECHANICAL DRIVES

OPTIMA designs and produces hydro-mechanical transmission units for special lorry applications. We develop individual solutions together with our partners and are dedicated to all challenges. OPS-782 combined drive systems (mechanical and hydrostatic).  Hydro-Mechanical drives, Hydrostatic Drive,  tailor-made gearboxes, custom made gearbox,

We wish you a happy new year

Auxiliary Drive

OPTIMA offers a wide range of auxiliary drives for heavy-duty industrial vehicles and with all kinds of specially customized solutions. • MERCEDES, VOLVO, SCANIA, ZF, EATON, and ALLISON gearboxes.  Parker Chelsea 489 Series Power Take-Off (PTO), Chelsea 280 Series is a hydraulically shifted hot shift PTO, Chelsea 210 Series PTO, Chelsea 249 Series PTO, Chelsea 870-XL Series Powershift PTO, Chelsea 267 Series is a 10-Bolt PTO designed to fit Allison and CAT automatic transmissions, Chelsea 880 Series, Chelsea 645 Series, Chelsea 870 Series powershift PTO, Chelsea 912 Series Split Shaft PTO/gear box, Chelsea 890 Series, Chelsea 524 Series Rear Mount PTO, Chelsea 272 Series Hot Shift 6-Bolt PTO, Chelsea 442 Series, Chelsea 680 Series PTO, Chelsea 249V Series, Chelsea 272-F Series, Chelsea 823 Series, Chelsea 897 Series, Chelsea 877 Series, Chelsea 282, Chelsea 340, Chelsea 221, Chelsea 626, Chelsea 628, Chelsea 630, Chelsea 660, Chelsea 852, Chelsea 541, Chelsea 885, Chelsea 252, 287 is a Heavy Duty Constant Mesh PTO, Chelsea 447 Series, Chelsea 901 Series Split Shaft gearbox, Chelsea 899 Series,  Chelsea 290 PTO, Mechanical Shift Rear Mount Power Take-Off (PTO) - 511 Series, 590 Series PowerShift (Hydraulic) Rear Mount PTO, Chelsea 348, Chelsea 2442 Series PTO, Chelsea 892 Series was designed to fit the Allison 4700 Series transmissions. Chelsea 863 Series Power Take-Off (PTO) is a Forward and Reverse PTO, Chelsea 352 Series PTO, Chelsea 247, Chelsea 877-XL Series PowerShift PTO, Chelsea 100 Series PTO, Chelsea 2230U Series Front Mount Gear Box, Chelsea 230, Chelsea 231 Series, Chelsea 236 Series, Chelsea 238 Series, Chelsea 243 Series, Chelsea 269 Series, Chelsea 270,  Chelsea 271 Series, Chelsea 277, Chelsea 278, Chelsea 429, Chelsea 435 Series Power Take-Off (PTO), Chelsea 452 Series Dual Shaft Power Take-Off (PTO), Chelsea 522 Series Rear Mount PTO was designed for the ZF, Chelsea 523 Series, Chelsea 800 Series, Chelsea 812, Chelsea 859, Chelsea 867, Chelsea 941 Series Split Shaft PTO/gearbox, Chelsea & Muncie PTO's & parts

Happy New Year

We want to wish you and your families a lovely and peaceful holiday season as well as a successful start into the next year!

IAA COMMERCIAL VEHICLES

Optima Drive Components will be in IAA Commercial Vehicles show at Hannover-Germany. The show will run from 20  to 27 September 2018. Meet with us...

IFAT Germany

Optima Drive Components will be in IFAT 2018 at Messe München, Germany, the world’s leading trade fair for water, sewage, waste and raw materials management. The show will run from 14 May to 18 May 2018. Meet with us...

DIRECT MOUNT TRANSFER CASE

Optima Getriebe offers Direct Mount Transfer Cases for 4x4 vehicles. Which is suitable for Allison transmissions.

REDUCTION GEARBOX

Optima produces multi-purpose gearboxes for special requirements.

UNLIMITED POSSIBILITIES

Optima transfer cases are available in single- and two-speed versions.

LASER BRANDING

Optima uses the latest technology in the production process, even branding.
